Operation Manual
er900L Operation Manual
28
Version: 12/01
Art-Nr: 475.043
Ergometer
Type er900L
#
First blood pressure measurement during recovery
Blood pressure measurements continue to be taken during the recovery phase at the set
interval.
Output of measured blood pressure data
The resulting blood pressure data are either printed by the internal printer or passed over the
RS-232 interface to an ECG for documenting there.
"
"
"
n-th blood pressure measurement during recovery
Blood pressure measurements continue to be taken during the recovery phase at the interval
set.
Output of measured blood pressure data
The resulting blood pressure data are either printed by the internal printer or passed over the
RS-232 interface to an ECG for documenting there.
Concluding ergometry
Ergometry is terminated completely by pressing the red coloured „END“ key for a second time
Output of the summary protocol
The termination protocol is either printed by the internal printer or passed over the RS-232
interface to an ECG for documenting there.
2
!
This process flowchart is only representative when the interval for blood pressure
measurements and load increment are equal, otherwise the sequence of mea-
surements and print-outs will be altered. Data output occurs basically at every
value change in blood pressure or load. The sequence will also be altered if the
program is manually modified.
Ergometry process
