Operation Manual
Version: 12/01
49
er900L Operation Manual
Art-Nr: 475.043
Ergometer
Type er900L
Program flowchart:
Structure of Programs
Patients with unknown circulatory conditions
select program 0
If necessary, change circulation alarm parameters
Start program (quiescent blood pressure measurement)
Print-out of resulting data
Load program start at Po
Print-out of the loaded data with every blood pressure measurement
Calculation of standard increments via 2-3 free load increments, subsequently
stressing with 3 standard load increments to reach the max. heart rate
Load program termination (caused by reaching an alarm parameter, dropping
below the minimum RPM rating of 25 RPM or because
the „END“ key was pressed - transition to the recovery phase
Print-out of measurement results for the on-going
blood pressure measurements
Terminate ergometry by again pressing the „END“ key
Output of the summary protocol
