Operation Manual
Version: 12/01
61
er900L Operation Manual
Art-Nr: 475.043
Ergometer
Type er900L
Appendix A: Interfaces
DATE 14.06.91 TIME 08.23
LOAD (watt) 000 HR (pulse/min) XXX
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
LOAD (watt) XXX
LOAD (watt) XXX
TORQUE (n(min) XXX TIME 08.24
LOAD (watt) XXX HR (pulse/min) XXX
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
LOAD (watt) XXX
LOAD (watt) XXX
TORQUE (n(min) XXX TIME 08.27
LOAD (watt) XXX HR (pulse/min) XXX
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
LOAD (watt) XXX
LOAD (watt) XXX
TORQUE (n(min) XXX TIME 08.27
LOAD (watt) XXX HR (pulse/min) XXX
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
LOAD (watt) XXX
LOAD (watt) XXX
DATE 14.06.91 TIME 08.28
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
HR (pulse/min) XXX
DATE 14.06.91 TIME 08.29
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
HR (pulse/min) XXX
DATE 14.06.94 TIME 0829
P max (watt) XXX HR (pulse/min) XXX
PWC110 (watt) XXX PWC110 (watt/kg) XXX
PWC130 (watt) XXX PWC130 (watt/kg) XXX
PWCXXX (watt) XXX PWCXXX (watt/kg) XXX
TRAININGSIND. = XXXXX
Protocol of
quiescent state
Protocol of load
program termination
Protocol of fourth
load step
Protocol of first load step
Load rep., begin increm.
Load rep., begin increm.
Load rep., begin increm.
Load rep., end increm.
Load rep., end increm.
Load rep., end increm.
Summary protocol at
the end of the entire er-
gometry
Protocol of second
recuperation audit
Protocol of first
recuperation audit
Load rep., begin increm.
Load rep., end increm.
Transmission Protocol
