ergoline Ergometrics er900L User Manual

Operation Manual
Version: 12/01
67
er900L Operation Manual
Art-Nr: 475.043
Ergometer
Type er900L
Transmission Protocol:
A protocol will automatically be produced at every blood pressure measurement and at every
load increment. This data will be sent to the RS-232 interface without a request from the
external device.
Control of load and blood pressure measurements as well as the monitoring of alarm para-
meters is handled internally from the console of the ergometer.
Appendix A: Interfaces
DATE 14.06.91 TIME 08.23
LOAD (watt) 000 HR ((pulse/min) XXX
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
TORQUE (n/min) XXX TIME 08.24
LOAD (watt) XXX HR (pulse/min) XXX
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
TORQUE (n/min) XXX TIME 08.27
LOAD (watt) XXX HR (pulse/min) XXX
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
TORQUE (n/min) XXX TIME 08.27
LOAD (watt) XXX HR (pulse/min) XXX
DATE 14.06.91 TIME 08.28
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
HR (pulse/min) XXX
DATE 14.06.91 TIME 08.29
SYSTOLE(mmHg) XXX DIASTOLE(mmHg) XXX
HR (pulse/min) XXX
DATE 14.06.94 TIME 0829
P max (watt) XXX HR (pulse/min) XXX
PWC110 (watt) XXX PWC110 (watt/kg) XXX
PWC130 (watt) XXX PWC130 (watt/kg) XXX
PWCXXX (watt) XXX PWCXXX (watt/kg) XXX
TRAININGSIND. = XXXXX
Protocol of quiescent
state
Protocol of first load
step
Protocol of fourth
load step
Protocol of load
program termination
Protocol of first
recuperation audit
Protocol of second
recuperation audit
Summary protocol at
the end of the entire
ergometry
•
•
•
