Description
10/2018
1020034-00
Operating instructions – 27/60
2.3 Device description
1. Base plate
2. Foot mat and vibration plate (Vibra Shape)
3. Operating panel
4. Holding bars
5. Fan (body cooling)
6. Loudspeakers
7. UV low pressure lamps
8. Interior lighting
9. Clamping strips (acrylic glass panels)
10. Supply air (body cooling)
11. Exhaust air (equipment cooling)
12. Height-adjustable feet
