Cleaning and maintenance
48/60
– Remove the screws and then remove the lamp cover.
Replacing lamps:
UV low pressure lamps: see page 46.
The assembly is the same process in reverse order.
When assembling the device please note:
– Insert the holding bar at the bottom with the hexagon in the recess of the
holding device and align.
DANGER!
Danger of crushing fingers when folding the clamping
strip!
Fingers can be crushed when folding the clamping strip.
– Do not hold fingers between the clamping strip and
acrylic glass panel when folding.
4.10 Cleaning or replacing the UV lamps on
the right
WARNING!
Acrylic glass panels unusable due to soiling!
Soiling on the panels is burned in by the hot lamps and
results in the long term in unserviceable panels.
– Remove fingerprints and other soiling carefully.
– Remove the screw.
