Radio Configurations, RBS 2106 and RBS 2206
Table 24 CDU-F configurations with a partly-equipped cabinet
SCC Configuration TMA Number of
Antennas
Allowed Number of dTRUs
1x4 F9de_2.4 No (2) (0) (0) (0..2) (0) (0)
F9det_2.4 M (2) (0) (0) (0..2) (0) (0)
F18d_2.4 No (2) (0) (0) (0..2) (0) (0)
F18dt_2.4 M (2) (0) (0) (0..2) (0) (0)
2x4 2 x F9de_2.4 No (2) (2) (0) (0..2) (0..2) (0)
2 x F9det_2.4 M (2) (2) (0) (0..2) (0..2) (0)
2 x F18d_2.4 No (2) (2) (0) (0..2) (0..2) (0)
2 x F18dt_2.4 M (2) (2) (0) (0..2) (0..2) (0)
1x8 F9de_2.8 No (2) (0) (0..4) (0)
F9det_2.8 M (2) (0) (0..4) (0)
F18d_2.8 No (2) (0) (0..4) (0)
F18dt_2.8 M (2) (0) (0..4) (0)
M = Mandatory
CDU-G Single Band Configurations without Hybrid Combiner
Table 25 CDU-G configurations without hybrid combiner in a fully or partly-equipped
cabinet
SCC Configuration TMA Number of
Antennas
Allowed Number of dTRUs
3x2 3 x G8d_2.2 No (2) (2) (2) (0..1) (0..1) (0..1)
3 x G8dt_2.2 M (2) (2) (2) (0..1) (0..1) (0..1)
3 x G9de_2.2 No (2) (2) (2) (0..1) (0..1) (0..1)
3 x G9det_2.2 M (2) (2) (2) (0..1) (0..1) (0..1)
3 x G18d_2.2 No (2) (2) (2) (0..1) (0..1) (0..1)
3 x G18dt_2.2 M (2) (2) (2) (0..1) (0..1) (0..1)
3 x G19d_2.2 No
1)
(2) (2) (2) (0..1) (0..1) (0..1)
3 x G19dt_2.2 M
1)
(2) (2) (2) (0..1) (0..1) (0..1)
M = Mandatory
1)
It is possible to mix cells with TMA and cells without TMA in the
same cell.
