Radio Configurations, RBS 2106 and RBS 2206
Table 26 CDU-G configurations without hybrid combiner in a partly-equipped cabinet only
SCC Configuration TMA Number of
Antennas
Allowed Number of dTRUs
1x2 G8d_2.2 No (2) (0) (0) (0..1) (0) (0)
G8dt_2.2 M (2) (0) (0) (0..1) (0) (0)
G9de_2.2 No (2) (0) (0) (0..1) (0) (0)
G9det_2.2 M (2) (0) (0) (0..1) (0) (0)
G18d_2.2 No (2) (0) (0) (0..1) (0) (0)
G18dt_2.2 M (2) (0) (0) (0..1) (0) (0)
G19d_2.2 No (2) (0) (0) (0..1) (0) (0)
G19dt_2.2 M (2) (0) (0) (0..1) (0) (0)
2x2 2 x G8d_2.2 No (2) (2) (0) (0..1) (0..1) (0)
2 x G8dt_2.2 M (2) (2) (0) (0..1) (0..1) (0)
2 x G9de_2.2 No (2) (2) (0) (0..1) (0..1) (0)
2 x G9det_2.2 M (2) (2) (0) (0..1) (0..1) (0)
2 x G18d_2.2 No (2) (2) (0) (0..1) (0..1) (0)
2 x G18dt_2.2 M (2) (2) (0) (0..1) (0..1) (0)
2 x G19d_2.2 No
1)
(2) (2) (0) (0..1) (0..1) (0)
2 x G19dt_2.2 M
1)
(2) (2) (0) (0..1) (0..1) (0)
M = Mandatory
1)
It is possible to mix cells with TMA and cells without TMA in the
same cell.
