Radio Configurations, RBS 2106 and RBS 2206
CDU-G Single Band Configuration with Hybrid Combiner
Table 27 CDU-G configurations with hybrid combiner in a fully- or partly-equipped cabinet
SCC
Configuration TMA Number of
Antennas
Allowed Number of dTRUs
3x4
3 x G8dh_2.4 No (2) (2) (2) (0..2) (0..2) (0..2)
3 x G8dht_2.4 M (2) (2) (2) (0..2) (0..2) (0..2)
3 x G9deh_2.4 No (2) (2) (2) (0..2) (0..2) (0..2)
3 x G9deht_2.4 M (2) (2) (2) (0..2) (0..2) (0..2)
3 x G18dh_2.4 No (2) (2) (2) (0..2) (0..2) (0..2)
3 x G18dht_2.4 M (2) (2) (2) (0..2) (0..2) (0..2)
3 x G19dh_2.4 No
1)
(2) (2) (2) (0..2) (0..2) (0..2)
3 x G19dht_2.4 M
1)
(2) (2) (2) (0..2) (0..2) (0..2)
2x6 2 x G8dh_3.6 No (3) (3) (0..3) (0..3)
2 x G8dht_3.6 M (3) (3) (0..3) (0..3)
2 x G9deh_3.6 No (3) (3) (0..3) (0..3)
2 x G9deht_3.6 M (3) (3) (0..3) (0..3)
2 x G18dh_3.6 No (3) (3) (0..3) (0..3)
2 x G18dht_3.6 M (3) (3) (0..3) (0..3)
2 x G19dh_3.6 No
1)
(3) (3) (0..3) (0..3)
2 x G19dht_3.6 M
1)
(3) (3) (0..3) (0..3)
1x12 G8dh_6.12 No (6) (0..6)
G8dht_6.12 M (6) (0..6)
G9deh_6.12 No (6) (0..6)
G9deht_6.12 M (6) (0..6)
G18dh_6.12 No (6) (0..6)
G18dht_6.12 M (6) (0..6)
G19dh_6.12 No (6) (0..6)
G19dht_6.12 M (6) (0..6)
M = Mandatory
SCC 1 x 2 and 2 x 2 can be achieved as a subset of SCC 3 x 4.
SCC 1 x 4 can be achieved as a subset of either SCC 3 x 4 or 2 x 6.
SCC 1 x 6 can be achieved as a subset of SCC 2 x 6.
SCC 2 x 4 can be achieved as a subset of SCC 3 x 4 or 2 x 6.
SCC 3 x 2 can be achieved with use of SCC 3 x 4.
SCC 1 x 2 and 1 x 4 require one CDU-G.
SCC 2 x 2 and 1 x 6 require two CDU-Gs.
SCC 3 x 2 requires three CDU-Gs.
1)
It is possible to mix cells with TMA and cells without TMA in the
same cell.
