10
GBGB
GBGB
GB
P3 = Full scale valueP3 = Full scale value
P3 = Full scale valueP3 = Full scale value
P3 = Full scale value
Not present when P1 = 5
Full scale value used by the PID algorithm to
calculate the input span.
P3 is programmable within the input span
selected by P1.
When P3 has been modified, the instrument
assignes to the rH parameter the new P3 value.
NOTENOTE
NOTENOTE
NOTE: the minimum input span (P3 - P2) is
- 300 °C or 600 °F for TC input
- 100 °C or 200 °F for RTD input.
P4 = Output configurationP4 = Output configuration
P4 = Output configurationP4 = Output configuration
P4 = Output configuration
H = heating
HC = heating/cooling
P5 = Main output typeP5 = Main output type
P5 = Main output typeP5 = Main output type
P5 = Main output type
rEL = Relay output.
SSr = SSR output.
NOTENOTE
NOTENOTE
NOTE:
Setting P5 = rEL, the C parameter will be
automatically set to 20 s.
Setting P5=SSr, the C parameter will be
automatically set to 2 s.
P6 = Cooling output typeP6 = Cooling output type
P6 = Cooling output typeP6 = Cooling output type
P6 = Cooling output type
Available only when P4 = HC
AIr = air
OIL = oil
H2O = water
NOTENOTE
NOTENOTE
NOTE:
Setting P6 = Air, the C2 parameter will be
automatically set to 10 s
and rC parameter will be
set to 1.00.
Setting P6=OiL, the C2 parameter will be au-
tomatically set to 4 s and rC
parameter will be set to 0.80.
Setting P6=H2O, the C2 parameter will be au-
tomatically set to 2 s and rC
parameter will be set to 0.40.
P7 = Alarm 1P7 = Alarm 1
P7 = Alarm 1P7 = Alarm 1
P7 = Alarm 1
Available only when P4 = H.
0 = Not provided
1 = Process alarm
2 = Band alarm
3 = Deviation alarm
P8 = Alarm 1 operative modeP8 = Alarm 1 operative mode
P8 = Alarm 1 operative modeP8 = Alarm 1 operative mode
P8 = Alarm 1 operative mode
Available only when P7 is different from 0 and
P4 = H.
H.A = high alarm (outside band) with automatic
reset
L.A = low alarm (inside band) with automatic reset
H.L= high alarm (outside band) with manual reset
L.L= low alarm (inside band) with manual reset
P9 = Stand by (mask) of the alarm 1P9 = Stand by (mask) of the alarm 1
P9 = Stand by (mask) of the alarm 1P9 = Stand by (mask) of the alarm 1
P9 = Stand by (mask) of the alarm 1
Available only when P7 is different from 0 and
P4 = H.
OFF = stand by (mask) disabled
ON = stand by (mask) enabled
NOTENOTE
NOTENOTE
NOTE: the alarm stand by function allows to
disable the alarm indication at instrument start up
or, for band and deviation alarms, after a set point
modification.
The alarm will be automatically reactivated when
the initial alarm condition disappears.
