ero electronic TMS - Default Parameters

A. 1
DEFAULT PARAMETERSDEFAULT PARAMETERS
DEFAULT PARAMETERSDEFAULT PARAMETERS
DEFAULT PARAMETERS
DEFAULT OPERATIVE PARAMETERSDEFAULT OPERATIVE PARAMETERS
DEFAULT OPERATIVE PARAMETERSDEFAULT OPERATIVE PARAMETERS
DEFAULT OPERATIVE PARAMETERS
The control parameters can be loaded with
predetermined default values. These data are the
typical values loaded in the instrument prior to
shipment from factory. To load the default values
proceed as follows:
a) The internal switch should be closed.
b) The SMART function should be disabled.
c) The upper display will show the process
variable while the lower display will show the
set point value or the current measure.
d) Held down  pushbutton and press 
pushbutton; the display will show:
e) Within 10 seconds press  or  pushbutton.
The display will show:
g) Press FUNC pushbutton; the display will show:
This means that the loading procedure has been
initiated. After about 3 seconds the loading
procedure is terminated and the instrument
reverts to NORMAL DISPLAY mode.
The following is a list of the default operative
parameters loaded during the above procedure:
PARAMETER DEFAULT VALUE
SP = minimum range-value
n.rS = OFF
nnn =OFF
A1, A2 = minimum range-value for
process alarms
0 for deviation or band alarms
H1, H2 = 0.1 %
Pb = 4.0 %
hS =0.5 %
ti = 04.0 (4 minutes)
td = 1.00 (1 minute)
IP = 30 % for 1 control output
0 % for two control outputs
C = 20 seconds for relay output
2 seconds for SSR output
C2 = 10 seconds for P6 = AIr
4 seconds for P6 = OIL
2 seconds for P6 = H2O
rC = 1.00 for P6 = AIr
0.80 for P6 = OIL
0.40 for P6 = H2O
OLP =0
rL = initial scale value
rH = full scale value
rP = infinite (step transfer)
OLH =100 %
tOL =infinite
Hbd = 50 % of the full scale value.
O F FO F F
O F FO F F
O F F
D F L D F L
D F L D F L
D F L
O nO n
O nO n
O n
D F L D F L
D F L D F L
D F L
L. d t.L. d t.
L. d t.L. d t.
L. d t.
