ESAB Aristo Robust Feed U6 - Page 13

4 INSTALLATION
0446 253 101
- 13 -
© ESAB AB 2020
CAUTION!
Do not place heavy objects on or attached to the wire feeder when lifting. The lifting
points are rated for a maximum total weight of 44 kg / 97 lb. when lifted in the two
outer upper lifting handles according to the graphic above!
The 44kg / 97lb. approved weight consists of wire feeder plus accessories (standard
feeder weight is 18.5kg / 40.8lb., for all weights see the TECHNICAL DATA chapter).
