ESAB EAC 10 - Diagrams and Component Identification; Component Identification

DIAGRAM
0463 609 101
- 17 -
© ESAB AB 2020
DIAGRAM
Component Description
1AP1 MMC module
1AP2 Display
1AP3 Buttons, rubber keypad
24AP1 Analogue interface board
26AP1 Motor control board
26AP2 Motor driver board
1L1, 26L1, X1L1 Ferrite ring cores
H1 On/off indicator
BR1 Rectifier bridge
C2 Filter capacitor
S1 Power switch
X1 Terminal block
XP1 Connector for digital power source
XP2 Connector for analogue power source
XP3 Connector for carrier
XP4 Connector for weld head
XP5 Connector for work piece voltage reference
