3 TECHNICAL DATA
0463 609 101
- 8 -
© ESAB AB 2020
3 TECHNICAL DATA
EAC 10, from serial no. 841-xxx-xxxx and 905-xxx-xxxx
Supply voltage 60VDC or 42VAC, 50/60Hz
Supply voltage to control
pendant
12VDC
Power requirement Max 900VA
Motor connections adapted
for ESAB motors
6A 100%
Speed control Feedback from pulse encoder
Operating temperature -10to +40°C (-14to +104°F)
Storage temperature -20to +55°C (-4 to +131°F)
Relative air humidity Max 95%
Dimensions l×w×h
EAC 10, complete control unit 275×300×165mm (10.8×11.8×6.5in.)
EAC 10 control pendant 245×225×50mm (9.7×8.9×2.0in.)
Weight
EAC 10, complete control unit 6.8kg (15lb)
EAC10 control pendant 1.25 kg (2.8 lb)
Enclosure class IP23
