5 OPERATION
0463 815 101 - 34 - © ESAB AB 2021
Spool gun
1 Trigger switch
2 Max (CW)
3 Min (CCW)
4 Pot V-A-WFS
5 Peripheral sense
MIG Gun (F180TH103035) / TIG Torch (W4013802)
1 Trigger switch
MIG Gun / TIG Torch
1 Trigger switch
2 10k Peripheral sense
