ESAB MXL 200 - 4 Technical Data

4 TECHNICAL DATA
0459 560 101
- 9 -
© ESAB AB 2017
4 TECHNICAL DATA
Welding torch MXL 150v MXL 200 MXL 270 MXL 340
Type of cooling Air Air Air Air
Permitted load at 20% intermittence *
Carbon dioxide CO
2
150 A
Mixed gas, Ar/CO
2
150 A
Permitted load at 35% intermittence *
Carbon dioxide CO
2
120 A 200 A 270 A 340 A
Mixed gas, Ar/CO
2
120 A 170 A 260 A 320 A
Recommended gas flow 8-15
l/min
10-18
l/min
10-18
l/min
10-20
l/min
Max pressure 2.5 bar
Wire diameter 0.6-0.8 mm 0.6-1.0 mm 0.8-1.2 mm 0.8-1.2 mm
Weight
2.5 m hose package 1.1 kg − − −
3.0 m hose package − 1.6 kg 2.2 kg 2.6 kg
4.0 m hose package − 2.0 kg 2.6 kg 3.7 kg
Cable assembly
Standard length 2.5 m 3.0 m / 4.0 m 3.0 m / 4.0 m 3.0 m / 4.0 m
Standard−control cable 2−pole 2−pole 2−pole 2−pole
* The capacity my be reduced up to 30% when pulse welding.
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or
cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.
General torch data with reference to IEC/EN 60 974−7
Type of voltage: DC voltage
Wire type: Standard round wire
Voltage measurement: Peak value of 113V
Connection protection equipment side (EN 60
529):
IP3X
Shielding gas: CO
2
or Ar/CO
2
