WEAR PARTS
0463 697 001
- 26 -
© ESAB AB 2021
XCT-B 400W
Nozzles, collets, collet bodies and gas lenses:
Bold = standard delivery
Item Size Description Ordering no.
1 Long
Medium
Short
Back cap 0700 025 650
0700 025 651
0700 025 652
2 Heat shield 0700 025 653
3 Ø 1.6
Ø 2.4
Ø 3.2
Ø 4.0
Collet standard 0700 025 654
0700 025 655
0700 025 656
0700 025 657
4 Ø 6.4 (No. 4)
Ø 8.0 (No. 5)
Ø 9.8 (No. 6)
Ø 11.2 (No. 7)
Ø 12.7 (No. 8)
Ø 16.0 (No. 10)
Gas nozzle standard
L=25.5mm
0157 121 032
0157 121 033
0157 121 034
0157 121 039
0157 121 040
0700 025 698
5 Ø 6.4 (No. 4)
Ø 8.0 (No. 5)
Ø 9.8 (No. 6)
Ø 11.2 (No. 7)
Ø 16.0 (No. 10)
Gas nozzle standard
L=35.0mm
0700 025 658
0700 025 659
0700 025 660
0700 025 661
0700 025 699
