3 TECHNICAL DATA
Warrior 500i CC/CV
Mains voltage 380 V; 440 V; 460 V; 575 V ±10%,
3~ 50/60 Hz
Primary current
I
max.
GMAW - MIG
I
max.
GTAW - TIG
I
max.
SMAW - MMA
38 A
31 A
38 A
No load power in energy-saving mode 6.5 min. after
welding 40 W
Setting range
GMAW - MIG flat characteristic
GTAW - TIG drooping characteristic
SMAW - MMA drooping characteristic
16 A/15 V-500 A/39 V
5 A/10 V-500 A/30 V
16 A/20 V-500 A/40 V
Permissible load at GMAW
60% duty cycle
100% duty cycle
500 A/39 V
400 A/34 V
Permissible load at GTAW
60% duty cycle
100% duty cycle
500 A/30 V
400 A/26 V
Permissible load at SMAW
60% duty cycle
100% duty cycle
500 A/40 V
400 A/36 V
Power factor at maximum current
GMAW
GTAW
SMAW
0.87
0.83
0.87
Efficiency at maximum current
GMAW
GTAW
SMAW
90%
88%
90%
Electrode types Basic
Rutile
Cellulosic
Open-circuit voltage without VRD function 84 V DC
Apparent power at maximum current 31.7 kVA
Active power at maximum current 22.6 kW
Operating temperature -50 to 104°F (-10 to 40°C)
Transportation temperature -68 to 131°F (-20 to 55°C)
Constant sound pressure when idling <70 db (A)
