1.2 Airflow Adjustment
The speed controller is located in the electrical panel at the top of the cabinet.
Plug the multimeter probes to the Motor Voltage Sampling Port. Use the multimeter to take the
motor voltage with corresponding air velocityreading. Adjust the airflow by adjusting the
speed controller. Use the knob provided to adjust the speed controller.
Knob
Speed controller
Adjust the speed controller by turning on the knob.
