4. Technical Data
4.1 General Technical Data
Temperature
range
0...50°C ambient temperature
Humidity 90 %, non-condensing
Power supply
via USB 2.0 bus,
nominal voltage: 5 V
current consumption: max. 250 mA
Connectors
X210 (DSUB9/male) - CAN bus
X300 (USB socket, series B) - USB bus
Case
dimensions
55 mm x 55 mm x 25 mm
IP-rating IP 40
Weight 140 g
Table 2: General data of the module
NOTICE
Please note that the current consumption of the module of 250 mA has to be supplied
(high powered bus-powered device).The maximum current consumption of 250 mA has
to be guaranteed also if a hub is used. Therefore it is highly recommended to use a self-
powered hub.
4.2 USB Interface and Microcontroller
USB interface USB 2.0, bit rate up to 480 Mbit/s
Microcontroller ARM7 microcontroller
Table 3: USB interface and microcontroller
Page 12 of 28
Hardware Manual • Doc. No.: C.2066.21 / Rev. 1.6
CAN-USB/2
