Kongsberg X-series
12.8.10. Bit Slipping, Chuck Change
Even though the chuck is expected to have a long lifetime, replace it immediately if you experience any
problems as:
1.
Bit slipping.
2.
Bit vibrations.
When replacing the chuck, follow instructions in
Chuck Change and Clean.
New chucks are available from Esko store.
12.8.11. Bit Length and Position
Keep distance d small.
For best performance and minimum wear, do not
let the bit stick out more than necessary.
Use bits with short cutting lengths for thin
materials.
For proper clamping, keep distance e 20 mm, 0.8
inch as a minimum.
If distance d is more than 28 mm / 1.1 inch,
be aware that the bit then extends below the
underside of the traverse.
If the machine has extended traverse clearance,
distance d must be 20 mm / 0.8 inch as a
minimum to be able to cut through the material.
111
