• Service and maintenance are not carried out strictly in accordance with the instructions, repair
work is not carried out by our personnel or has been performed without prior written consent.
• The TakeUp Unit is modified without prior written consent; non-original parts are used.
• The equipment is used inexpertly, incorrectly, carelessly or not accordance with its nature or
intended use.
Wearing parts are not covered by the warranty
Safety
Familiarize yourself with the pictograms.
The equipment is provided with safety and protection features.
Even so, caution is necessary when performing machine operations.
Warning pictograms in the various sections point to potential dangers. You will find these pictograms
near the text referring to the operations risks.
Work safely!
We have made everly effort to inform you as correctly and completely as possible on any dangers
associated with the operation of the machine.
You must ensure and are responsible for compliance with these behavioural guidelines.
The buyer/user is obliged to familiarize operating, cleaning and maintenance personnel with these
instructions .
18.2. Machine Description
The TakeUp Unit is a machine specially developed to take-up media, with minimum pull on the media.
Frame
The frame of the TakeUp Unit consists out of two metal frame plates which are connected to each
other by a folded plate.
The main electrical components are mounted on the left frame plate.
The left and right side of the TakeUp Unit are protected with metal cover plates which are mounted to
the frame plates. Other machine sub-assemblies are mounted in between the both metal frame plates
Operation
There is one switch on the left top-side of the TakeUp Unit.
This switch switches the machine on and off.
