19
Kongsberg X-series
13.
The MRF is now ready to be used.
14.
Bring the material to the front of the Cutting Table using the joystick on the Traverse or on the
Operator Station.
19.6.4. End of production
The Motorized Roll Feeder is not equipped with an end of roll sensor. It is therefore necessary to make
sure that the material is not fixed to the core. Use easy to removable tape or no tape when printing. If
tape can be avoided, this is an advantage, because angular tension is not built up when winding up your
material when printing.
The MRF will stop when the dancer falls to the lowest position (material being pulled off from the core).
The MRF will stop when the dancer is pulled to the highest position (material fixed to core).
Put the Automatic Winding Direction switch (A) back in the neutral position when the roll is finished.
19.6.5. Intelligent vacuum
To ensure maximum blowback when feeding, Intelligent Vacuum Control should be disabled in iPC, and
all the zones should be opened.
19.7. Safety
• The system is equipped with two Emergency stop buttons on each side. The switches are
connected to the safety of the table, which means both the Cutting Table and the MRF will stop
operating when pressed.
• The MRF will stop operating if the DynaGuard safety system of the table is triggered.
• The Motorized Roll Feeder does not have an end of roll sensor. It is therefore necessary to make
sure that the material is not fixed to the core. Use easy to removable tape or no tape when printing.
If tape can be avoided, this is an advantage, because angular tension is not built up when winding up
your material when printing. The Motorized Roll Feeder will stop when the dancer falls to the lowest
position or is pulled towards the highest position.
204
