Specifications
Playable disc types
Super Audio CD, CD (including CD-R and CD-RW)
Analog audio outputs
XLR ....................................................... 1 pair (L/R)
Maximum output level ................................... 5.0Vrms
Output impedance ......................................... 114Ω
RCA ...................................................... 1 pair (L/R)
Maximum output level ................................... 2.5Vrms
Output impedance .......................................... 34Ω
Audio performance
(when Super Audio CD at 0 dB, DSDF is F2, XLR output)
Frequency response ........................ 5Hz to 70kHz (−3dB)
S/N ratio ....................................... 113dB (A-Weight)
Distortion ........................................ 0.0007% (1kHz)
Digital audio outputs
XLR ................................................................. 1
Output level ............................................... 3Vp-p
Output impedance ......................................... 110Ω
Output signal format ....................... Linear PCM (AES/EBU)
44.1kHz/16-bit (during CD playback)
RCA ................................................................ 1
Output level .............................................. 0.5Vp-p
Output impedance .......................................... 75Ω
Output signal format ...................... Linear PCM (IEC 60958)
44.1kHz/16-bit (during CD playback)
Digital audio inputs
RCA ................................................................ 1
Input level ............................................... 0.5Vp-p
Input impedance ........................................... 75Ω
Input signal formats
Linear PCM (IEC 60958) .............. 32–192kHz/16-bit, 24-bit
DSD (DoP) ............................................ 2.8MHz
OPTICAL ............................................................ 1
Input level ...............................−24.0 to −14.5dBm peak
Input signal formats
Linear PCM (IEC 60958) ...............32–192kHz/16-bit, 24-bit
DSD (DoP) ............................................ 2.8MHz
USB ................................................................ 1
(B-type connector, supports USB 2.0)
Input signal formats
Linear PCM ..................44.1–384kHz/16-bit, 24-bit, 32-bit
DSD ..................... 2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz
Clock input
BNC ................................................................ 1
Input level ................................. 0.5 to 1.0Vrms (sine wave)
Input impedance ............................................... 50Ω
Frequencies that can be input (±10 ppm) .................... 10MHz
External control input
RS-232C ............................................................ 1
Trigger (TRIG) ...................................................... 1
(3.5mm mono mini jack)
Input level ............................................ 12V, 55mA
General
Power supply
Model for Europe ..........................AC 220–240V, 50/60Hz
Model for USA/Canada ............................AC 120V, 60Hz
Model for Korea ...................................AC 220V, 60Hz
Model for Hong Kong .............................AC 230V, 50Hz
Power consumption
K-01XD ...................................................... 26W
K-03XD ...................................................... 25W
External dimensions (W × H × D, including protrusions)
445 × 162 × 438 mm (17 5/8" × 6 1/2" × 17 1/4")
Weight
K-01XD ........................................... 31kg (683/8lb)
K-03XD ........................................... 28kg (613/4lb)
Operating temperature ................................ +5°C to +35°C
Operating humidity range ............. 5% to 85% (no condensation)
Storage temperature ................................ −20°C to +55°C
Included accessories
Power cord × 1
Remote control (RC-1333) × 1
Batteries for remote control (AA) × 2
Felt pads × 3
Owner’s manual (this document) × 1
Warranty card × 1
o Specifications and appearance are subject to change without
notice.
o Weight and dimensions are approximate.
o Illustrations in this Owner’s Manual might differ slightly from
production models.
