Esoteric K-01XD - Product Dimensions; Physical Size & Footprint Diagram

32
445 438
162
Foot placement diagram
307
403
232 23745
3-Φ48
o These dimensional drawings show the K-01XD.
o The dimensions of the K-03XD are the same.
Dimensions in millimeters (mm)
*48mm diameter feet × 3
Dimensional drawings
