Specifications
Playable disc types
Super Audio CD, CD (including CD-R and CD-RW)
Analog audio outputs
XLR ....................................................... 1 pair (L/R)
Maximum output level ................................... 5.0Vrms
Output impedance ......................................... 114Ω
RCA ...................................................... 1 pair (L/R)
Maximum output level ................................... 2.5Vrms
Output impedance .......................................... 57Ω
Audio performance
(when Super Audio CD at 0 dB, DSDF is F2, XLR output)
Frequency response ........................ 5Hz to 70kHz (−3dB)
S/N ratio ....................................... 110dB (A-Weight)
Distortion ........................................ 0.0007% (1kHz)
Digital audio outputs
XLR ................................................................. 1
Output level ............................................... 3Vpp
Output impedance ......................................... 110Ω
Output signal format ....................... Linear PCM (AES/EBU)
44.1kHz/16-bit (during CD playback)
COAXIAL ........................................................... 1
Output level .............................................. 0.5Vpp
Output impedance .......................................... 75Ω
Output signal format ......................Linear PCM (IEC 60958)
44.1kHz/16-bit (during CD playback)
Digital audio inputs
COAXIAL ........................................................... 1
Input level ................................................0.5Vpp
Input impedance ........................................... 75Ω
Input signal formats
Linear PCM (IEC 60958) .............. 32–192kHz/16-bit, 24-bit
DSD (DoP) ............................................ 2.8MHz
OPTICAL ............................................................ 1
Input level ...............................−24.0 to −14.5dBm peak
Input signal formats
Linear PCM (IEC 60958) .............. 32–192kHz/16-bit, 24-bit
DSD (DoP) ............................................ 2.8MHz
USB ................................................................ 1
(B-type connector, supports USB 2.0)
Input signal formats
Linear PCM .................. 44.1–384kHz/16-bit, 24-bit, 32-bit
DSD ..................... 2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz
Clock input
BNC ................................................................ 1
Input level ................................. 0.5 to 1.0Vrms (sine wave)
Input impedance ............................................... 50Ω
Frequencies that can be input (±10 ppm) .................... 10MHz
External control input
RS-232C ............................................................ 1
Trigger (TRIGGER IN) ...............................................1
(3.5mm mono mini jack)
Input level .............................................. 12V, 2mA
General
Power supply
Model for Europe ......................... AC 220–240V, 50/60Hz
Model for USA/Canada ............................ AC 120V, 60Hz
Power consumption ............................................ 25W
In standby
Remote control input (RS-232C) connector setting OFF ...0.3W
Remote control input (RS-232C) connector setting ON ...0.6W
External dimensions (W × H × D, including protrusions)
445 × 161 × 357mm (17 5/8" × 6 3/8" × 14 7/8")
Weight ............................................ 20.7kg (45 3/4lb)
Operating temperature range ......................... +5°C to +35°C
Operating humidity range ............. 5% to 85% (no condensation)
Storage temperature range .......................... −20°C to +55°C
Included accessories
Power cord × 1
Remote control (RC-1333) × 1
Batteries for remote control (AA) × 2
Felt pads × 3
Owner’s manual (this document) × 1
Warranty card × 1
o Specifications and appearance are subject to change without notice.
o Weight and dimensions are approximate.
o Illustrations in this manual might differ slightly from production
models.
