2. Remove the rubber ring from between the
plates.
3. Reassemble the side plates with a new
rubber ring.
When reassembling the friction wheel
assembly, make sure that rubber ring is
centered and seated properly between the
side plates. Tighten each screw only one
rotation before turning the wheel clockwise
and proceeding with the next screw on the
other side of the wheel. Repeat this
process several times to ensure the plates
are secured with equal force between
90N.m(6 ft-lbs) and 130N.m(9 ft-lbs).
4. Slide the friction wheel assembly back onto
the hex shaft. Make sure the shift lever pin is
in place in the bearing housing. Follow the
steps above in reverse order to reassemble
components.
Charging Battery (if so equipped)
Follow the instructions below to charge battery:
1. Remove battery cover.
2. Disconnect negative (black) battery cable first,
then positive (red) battery cable.
3. Take battery out of the tray and place it on
bench or other well-ventilated place.
4. Connect positive (+) lead of charger to
positive (+) terminal, and negative (-) lead to
negative (-) terminal.
5. Charge the battery at two and a half amps for
then hours.
6. Reinstall battery into unit.
TROUBLESHOOTING
Electric Starter does not
turn(on models so
equipped)
1. Extension cord not connected.
2. The Extension cord is worn,
corroded, or damaged.
3. The power outlet is not
1. Connect the extension cord to the
outlet and/or the machine.
2. Replace the extension cord.
3. Have a qualified electrician energize
Engine fails to start
1. Choke not in CHOKE position.
2. Engine not primed.
3. Engine is flooded.
4. Fuel shut-off valve closed.
5. Throttle in STOP position or
ON/OFF switch is OFF.
6. Spark plug wire loose or
disconnected.
7. Fuel tank empty or stale fuel.
8. Faulty spark plug.
9. Safety ignition key is not
inserted.
10. The engine oil level in the
engine crankcase is too low or
too high.
1. Move choke to CHOKE position.
2. Prime engine as instructed in this
manual.
3. Wait a few minutes before
restarting, DO NOT prime.
4. Open fuel shut-off valve.
5. Move throttle to FAST position or
ON/OFF switch to ON Position.
6. Connect or tighten spark plug wire.
7. Fill tank with clean, fresh gasoline.
8. Clean, adjust gap, or replace.
9. Insert safety ignition key.
10. Add or drain oil to adjust the oil
level in the engine crankcase.
Engine idles or runs
roughly
1. Engine running on CHOKE.
2. Fuel tank is nearly empty or
1. Move choke lever to RUN position.
2. Fill tank with clean, fresh gasoline.
