Do not placed the multiple socket-outlet for CSPOLA600 system on the floor in order to
prevent liquid penetration and damage to the product.
CSPOLA600 system shall not be connected with additional multiple socket-outlets or extension
cords in addition to a designated single multiple socket-outlet.
Maximum permissible load of each socket-outlet used for the CSPOLA600 system, shall not be
less than 60VA.
Do not connect the device which is not a supplement of CSPOLA600 with the multiple socket-
outlet of CSPOLA600.
Multiple socket-outlet should be a grounding-type and complied with IEC 60884-1.
Do not use the same system in an overlapping or adjacent area with other equipment, and if
adjacent or overlapping use is required, be sure to monitor the equipment or system to ensure
that it is functioning properly in the array in which it will be used.
View from A-A (male plug connected)
Connection of the plug shall be possible only by
using the tool.
1: Male plug ME equipment
2: Cover
3: Spacer
4: Plate fixed on MSO
5: MSO
Avoid places where the ambient temperature falls below 10° or exceeds 40° for normal operation, or below
-10°C or exceeds 55°C (14°C-131°C) for transportation and storage.
Humidity should be maintained between 30 and 85% (Atmospheric pressure : 70 to 106kPa) for normal
operation, or between 10 and 95% (Atmospheric pressure : 50 to 106kPa) for transportation and storage.
Avoid environments where the equipment is exposed to excessive shocks or vibrations.
