1. HOW TO INSTALL THE DEVICE
Danger of device fall. The electric table must be installed on a horizontal and stable surface.
Place the electric table in the room. The electric table must be lifted by two people.
If present, block the table wheels. Lower the lever of the brake.
Place the power supply under the support plane. Screw the screws in the four holes.
Place the device on the support surface on the cogged guides.
1
2
3
4
Retina550 - Fundus camera > V1 - 06-2017
24
USER MANUAL> IV. DEVICE USE
