2. HOW TO CONNECT THE DEVICE
With:
No. Denomination
1 USB connection cable between device and PC.
2 Power cable for the connection between the power supplier and the device.
3 Power cable for the connection of the electric table with the power supply.
4 Power cable for the connection of the electric table with the power supply.
Power points position Wireway
The power point is on the column of the electric table, below, and it has to be used for the
connection with the mains power. The power points on the column, on top, are dedicated to the
tools and power suppliers. Block the cables under the support surface with the cable rivets. If you
have it, place the cables in the wireway under the support plane.
