8
LCD
Color LCD with 640 X 480 dots
User-friendly LCD which is adjustable vertically within operating range (60°)
Touch panel is adopted.
Pilot lamp
Lamp to indicate ON (light on)/ OFF (light off) and power saving mode (blink)
Marking lever/ lens holder
The marking lever and lens holder are integrated.
・Marking lever： puts the dots by pressing the lever down.
・Lens holder: fixes the framed glass on the lens stand by moving the lever up and down.
Lens stand
Take a measurement by placing the framed lens on the lens stand.
Lens plate
The plate to be reference of the cylindrical axis and specified direction of the prism.
For the framed lens, take a measurement so as that the lens frame contacts with the lens plate.
Lens plate lever
Moves the lens plate back and forth
Nose pad
Used for measuring PD of the framed lens.
Set the framed lens so as that the nose pad is placed on it. The judgment of right and left and PD
measurement are performed based on the position of the nose pad.
Memory/Add switch
The switch to store the measurement values on the measurement screen of single focus lens,
multifocal lens and contact lens.
Freezes the display of the measurement values and store them.
The switch to execute the near and far points in case of manual measurement on the progressive
lens measurement screen
Communication connector
The communication connector to transfer the measurement data to the other devices and
computers.
Power inlet
The inlet to connect the power cord supplied to supply power.
Power supply switch
The switch to turn on/ off the power of the device
Printer
Prints out the measurement values
