6. Technical data and description
6.1 DUSTOMAT - 21 H to - 67 H
Type
(see model plate)
21/22/23/27 41/42/43/47 61/62/63/67
Max. airflow volume [m³/h] 1,060 1,330 1,500
Connection diameter [mm] 125 140 140
Max. vacuum [Pa] 3,550 3,800 4,350
Nominal volume flow [m³/h] 884 1,108 1,108
Minimum volume flow [m³/h] 795 997 997
Connection voltage [V] 400
Nominal frequency [Hz] 50
Drive output [kW] 2.2 3
Rated current [A] 4.5 6.3 6.3
Circuit breaker (A) 16
Filter area, dust class “M” [m²] 9.6
Filter area, dust class “H” [m²] 18
Dust collection container [litres] 200
Environmental conditions [°C]
525
Max. air humidity [%] 60
Dimensions [mm] 1,830 x 782 x 2,040
Weight [kg] 240 260 265
Max. sound pressure level Lpa* dB(A) 74 75 78
Production year See model plate
* = as per DIN EN ISO 3744, measurement margin of error approx. 4 dB(A)
We reserve the right to make technical changes.
