28 DUSTOMAT 21-67 H 09302-52-00
13. Device diagram
With the model information, request the replacement parts you need from
the ESTA replacement part service: +49 (0) 7307 804 - 0
DUSTOMAT- 21 to - 67 H
Mobile dust collection
container for undocking,
Tiltable filter
housing
Suction port for the
suction hose
User interface
Maintenance cover
locked with clamping
ring
Fan housing with discharge
openings
Air filtered on the suction side
Main filter (backup filter
cassette) placed on the fan
housing
