Estun E10 User Manual

E10 Operation Manual V1.15
Bending machine: the output OUT1,OUT2,OUT3 and OUT4 access relay coil externally.
When E10 hasn’t soft limit function:
Shearing machine : the output OUT1, OUT2, OUT3, OUT4 can be an external relay coil as a time
relay output.
Bending machine: with the Shearing machine.
Detailed in the table below:
Signal Function
0 1 2 3 4 5
Output 1 X min limit Relay1 Relay2 Relay 3 count
Output 2 X max limit Relay1 Relay2 Relay 3 count
Output 3 Y min limit Relay1 Relay2 Relay 3 count
Output 4 Y max limit Relay1 Relay2 Relay 3 count
Page 9 of 28
