E10 Operation Manual V1.15
Chapter 2 Specification
Technical Specification
1、Mounting dimension:
- Outer housing mount: 186*138*84
- Panel mount: 171*122*84
2、Panel specification:
- 2 rows of [6*7] segment LED display
- Filmy key-presses of high quality metal spring plate
3、Axis specification:
- Stroke range of X axis 0-999999mm/inch
- Stroke range of Y axis 0-999999mm/inch
- X axis display precision 0.1mm/inch
- Y axis display precision 0.01mm/inch
4、I/O channel specification:
- Output channel:
Relay normal on output, touch point electrical current
1A/DC24V or 0.5A/AC125V
- Input channel:
15mA input
5、Encoder specification:
- 50KHZ counting frequency
- Input voltage: DC 12V +/- 4%
- Maximum current: 200mA
6、Input power specification:
- DC 24V +/- 10%
- Maximum current: 1A
7、Surroundings temperature
- Working temperature
0～50℃
- Storage temperature
-20～70℃
Page 3 of 28
