E10 Operation Manual V1.15
4.2 introduction
4.2.1 LED lamp
There’s one LED lamp in the front panel:
LED lamp behind the first line digital display
------------Alarm LED. It will be lid if there’s no one-side positioning on
X-axis,which means screw rod gap still remains.
4.2.2 Keys
There are 5 membrane keys in front panel which could be divided into function key,
positioning keys and numerical keys according to the functions.
Function keys:
----------------------Mode key. Used for switching interface or canceling the modification
of the parameters.
Positional keys:
----------------------Leftward moving key, used during parameter editing to move the
cursor from current digit to one digit leftward.
----------------------Enter key. Used for confirming the modification of the parameters.
Numerical keys:
----------------------Increase key, used during parameter editing to increase current
parameter value with 1.(when current value is 9, it will be 0 after
pressing this key.)
----------------------Decrease key, used during parameter editing to decrease current
parameter value with 1.(when current value is 0, it will be 9 after
pressing this key.)
