CV Overview Chart
CVCV
CVCV
CV
NameName
NameName
Name
DescriptionDescription
DescriptionDescription
Description
RangeRange
RangeRange
Range
Def.Def.
Def.Def.
Def.
129 Assignment of function Assignment of function outputs activated in status „stop – forward“ 0-255 0
„stop“ forward A Bit Description value
0 headlights 1
1 back lights 2
2 function output AUX 1 4
3 function output AUX 2 8
4 function output AUX 3 16
5 function output AUX 4 32
6 function output AUX 5 (Loksound XL),
Diesel Notching Up (LSV3.5 und micro) 64
7 function output AUX 6 (Loksound XL),
Diesel Notching down (LSV3.5 und micro) 128
130 Assignment of function Assignment of function outputs activated in status „stop – forward“ 0-255 0
„stop“ forward B Bit Description value
0 acceleration on / off 1
1 shunting mode on / off 2
2 sound on / off 4
3 shift mode 8
4 Fan sound 16
5 Doppler on/off 32
6 Mute / Volume Control 64
7 Dynamic Brake 128
131 Assignment of function Assignment of function outputs activated in status „stop – forward“ 0-16 0
„stop“forward C Bit Description Value
0-3 Soundslot 1 - 16 0
132 Assignment of function Assignment of function outputs activated in status „stop – backward“ 0-255 0
„stop“ backward A refer to CV 129
133 Assignment of function Assignment of function outputs activated in status „stop – backward“ 0-255 0
„stop“ backward B refer to CV 130
134 Assignment of function Assignment of function outputs activated in status „stop – forward“ 0-16 0
„stop“ backward C Bit Description Value
0-3 Soundslot 1 - 16 0
135 Assignment of function Assignment of function outputs, activated in when driving forward;
Driving Forward A see CV129 0-255 0
136 Assignment of function Assignment of function outputs, activated in when driving forward;
Driving Forward B see CV130 0-255 0
137 Assignment of function Assignment of function outputs, activated in when driving forward;
Driving Forward C Soundslot 1 - 16 0-16 0
138 Assignment of function Assignment of function outputs, activated in when driving backward;
Driving Backward A see CV132 0-255 0
139 Assignment of function Assignment of function outputs, activated in when driving backward;
Driving Backward B see CV133 0-255 0
140 Assignment of function Assignment of function outputs, activated in when driving backward;
Driving Backward C Soundslot 1- 16 0-16 0
141 Assignment of function Assignment of function outputs, activated in light forward;
Light Forward A see CV129 0-255 0
142 Assignment of function Assignment of function outputs, activated in light forward;
Light Forward B see CV130 0-255 0
143 Assignment of function Assignment of function outputs, activated in light forward;
Light Forward C Soundslot 1 - 16 0-16 0
CVCV
CVCV
CV
NameName
NameName
Name
DescriptionDescription
DescriptionDescription
Description
RangeRange
RangeRange
Range
Def.Def.
Def.Def.
Def.
144 Assignment of function Assignment of function outputs, activated in light backward;
Light Backward A see CV132 0-255 0
145 Assignment of function Assignment of function outputs, activated in light backward;
Light Backward B see CV133 0-255 0
146 Assignment of function Assignment of function outputs, activated in light backward;
Light Backward C Soundslot 1- 16 0-16 0
147 Assignment of function Assignment of function outputs, activated in F1 forward;
F1 Forward A see CV129 0-255 0
148 Assignment of function Assignment of function outputs, activated in F1 forward;
F1 Forward B see CV130 0-255 0
149 Assignment of function Assignment of function outputs, activated in F1 forward;
F1 Forward C Soundslot 1 - 16 0-16 0
150 Assignment of function Assignment of function outputs, activated in F1 backward;
F1 Backward A see CV132 0-255 0
151 Assignment of function Assignment of function outputs, activated in F1 backward;
F1 Backward B see CV133 0-255 0
152 Assignment of function Assignment of function outputs, activated in F1 backward;
F1 Backward C Soundslot 1- 16 0-16 0
153 Assignment of function Assignment of function outputs, activated in F2 forward;
F2 Forward A see CV129 0-255 0
154 Assignment of function Assignment of function outputs, activated in F2 forward;
F2 Forward B see CV130 0-255 0
155 Assignment of function Assignment of function outputs, activated in F2 forward;
F2 Forward C Soundslot 1 - 16 0-16 0
156 Assignment of function Assignment of function outputs, activated in F2 backward;
F2 Backward A see CV132 0-255 0
157 Assignment of function Assignment of function outputs, activated in F2 backward;
F2 Backward B see CV133 0-255 0
158 Assignment of function Assignment of function outputs, activated in F2 backward;
F2 Backward C Soundslot 1- 16 0-16 0
159 Assignment of function Assignment of function outputs, activated in F3 forward;
F3 Forward A see CV129 0-255 0
160 Assignment of function Assignment of function outputs, activated in F3 forward;
F3 Forward B see CV130 0-255 0
161 Assignment of function Assignment of function outputs, activated in F3 forward;
F3 Forward C Soundslot 1 - 16 0-16 0
162 Assignment of function Assignment of function outputs, activated in F3 backward;
F3 Backward A see CV132 0-255 0
163 Assignment of function Assignment of function outputs, activated in F3 backward;
F3 Backward B see CV133 0-255 0
164 Assignment of function Assignment of function outputs, activated in F3 backward;
F3 Backward C Soundslot 1- 16 0-16 0
165 Assignment of function Assignment of function outputs, activated in F4 forward;
F4 Forward A see CV129 0-255 0
166 Assignment of function Assignment of function outputs, activated in F4 forward;
F4 Forward B see CV130 0-255 0
167 Assignment of function Assignment of function outputs, activated in F4 forward;
F4 Forward C Soundslot 1 - 16 0-16 0
168 Assignment of function Assignment of function outputs, activated in F4 backward;
F4 Backward A see CV132 0-255 0
169 Assignment of function Assignment of function outputs, activated in F4 backward;
F4 Backward B see CV133 0-255 0
170 Assignment of function Assignment of function outputs, activated in F4 backward;
F4 Backward C Soundslot 1- 16 0-16 0
