32
CVCV
CVCV
CV
NameName
NameName
Name
DescriptionDescription
DescriptionDescription
Description
RangeRange
RangeRange
Range
DefDef
DefDef
Def
171 Assignment of function Assignment of function outputs, activated in F5 forward;
F5 Forward A see CV129 0-255 0
172 Assignment of function Assignment of function outputs, activated in F5 forward;
F5 Forward B see CV130 0-255 0
173 Assignment of function Assignment of function outputs, activated in F5 forward;
F5 Forward C Soundslot 1 - 16 0-16 0
174 Assignment of function Assignment of function outputs, activated in F5 backward;
F5 Backward A see CV132 0-255 0
175 Assignment of function Assignment of function outputs, activated in F5 backward;
F5 Backward B see CV133 0-255 0
176 Assignment of function Assignment of function outputs, activated in F5 backward;
F5 Backward C Soundslot 1- 16 0-16 0
177 Assignment of function Assignment of function outputs, activated in F6 forward;
F6 Forward A see CV129 0-255 0
178 Assignment of function Assignment of function outputs, activated in F6 forward;
F6 Forward B see CV130 0-255 0
179 Assignment of function Assignment of function outputs, activated in F6 forward;
F6 Forward C Soundslot 1 - 16 0-16 0
180 Assignment of function Assignment of function outputs, activated in F6 backward;
F6 Backward A see CV132 0-255 0
181 Assignment of function Assignment of function outputs, activated in F6 backward;
F6 Backward B see CV133 0-255 0
182 Assignment of function Assignment of function outputs, activated in F6 backward;
F6 Backward C Soundslot 1- 16 0-16 0
183 Assignment of function Assignment of function outputs, activated in F7 forward;
F7 Forward A see CV129 0-255 0
184 Assignment of function Assignment of function outputs, activated in F7 forward;
F7 Forward B see CV130 0-255 0
185 Assignment of function Assignment of function outputs, activated in F7 forward;
F7 Forward C Soundslot 1 - 16 0-16 0
186 Assignment of function Assignment of function outputs, activated in F7 backward;
F7 Backward A see CV132 0-255 0
187 Assignment of function Assignment of function outputs, activated in F7 backward;
F7 Backward B see CV133 0-255 0
188 Assignment of function Assignment of function outputs, activated in F7 backward;
F7 Backward C Soundslot 1- 16 0-16 0
189 Assignment of function Assignment of function outputs, activated in F8 forward;
F8 Forward A see CV129 0-255 0
190 Assignment of function Assignment of function outputs, activated in F8 forward;
F8 Forward B see CV130 0-255 0
191 Assignment of function Assignment of function outputs, activated in F8 forward;
F8 Forward C Soundslot 1 - 16 0-16 0
192 Assignment of function Assignment of function outputs, activated in F8 backward;
F8 Backward A see CV132 0-255 0
193 Assignment of function Assignment of function outputs, activated in F8 backward;
F8 Backward B see CV133 0-255 0
194 Assignment of function Assignment of function outputs, activated in F8 backward;
F8 Backward C Soundslot 1- 16 0-16 0
195 Assignment of function Assignment of function outputs, activated in F9 forward;
F9 Forward A see CV129 0-255 0
196 Assignment of function Assignment of function outputs, activated in F9 forward;
F9 Forward B see CV130 0-255 0
197 Assignment of function Assignment of function outputs, activated in F9 forward;
F9 Forward C Soundslot 1 - 16 0-16 0
198 Assignment of function Assignment of function outputs, activated in F9 backward;
F9 Backward A see CV132 0-255 0
CVCV
CVCV
CV
NameName
NameName
Name
DescriptionDescription
DescriptionDescription
Description
Range Range
Range Range
Range
DefDef
DefDef
Def
199 Assignment of function Assignment of function outputs, activated in F9 backward;
F9 Backward B see CV133 0-255 0
200 Assignment of function Assignment of function outputs, activated in F9 backward;
F9 Backward C Soundslot 1- 16 0-16 0
201 Assignment of function Assignment of function outputs, activated in F10 forward;
F10 Forward A see CV129 0-255 0
202 Assignment of function Assignment of function outputs, activated in F10 forward;
F10 Forward B see CV130 0-255 0
203 Assignment of function Assignment of function outputs, activated in F10 forward;
F10 Forward C Soundslot 1 - 16 0-16 0
204 Assignment of function Assignment of function outputs, activated in F10 backward;
F10 Backward A see CV132 0-255 0
205 Assignment of function Assignment of function outputs, activated in F10 backward;
F10 Backward B see CV133 0-255 0
206 Assignment of function Assignment of function outputs, activated in F10 backward;
F10 Backward C Soundslot 1- 16 0-16 0
207 Assignment of function Assignment of function outputs, activated in F11 forward;
F11 Forward A see CV129 0-255 0
208 Assignment of function Assignment of function outputs, activated in F11 forward;
F11 Forward B see CV130 0-255 0
209 Assignment of function Assignment of function outputs, activated in F11 forward;
F11 Forward C Soundslot 1 - 16 0-16 0
210 Assignment of function Assignment of function outputs, activated in F11 backward;
F11 Backward A see CV132 0-255 0
211 Assignment of function Assignment of function outputs, activated in F11 backward;
F11 Backward B see CV133 0-255 0
212 Assignment of function Assignment of function outputs, activated in F11 backward;
F11 Backward C Soundslot 1- 16 0-16 0
213 Assignment of function Assignment of function outputs, activated in F12 forward;
F12 Forward A see CV129 0-255 0
214 Assignment of function Assignment of function outputs, activated in F12 forward;
F12 Forward B see CV130 0-255 0
215 Assignment of function Assignment of function outputs, activated in F12 forward;
F12 Forward C Soundslot 1 - 16 0-16 0
216 Assignment of function Assignment of function outputs, activated in F12 backward;
F12 Backward A see CV132 0-255 0
217 Assignment of function Assignment of function outputs, activated in F12 backward;
F12 Backward B see CV133 0-255 0
218 Assignment of function Assignment of function outputs, activated in F12 backward;
F12 Backward C Soundslot 1- 16 0-16 0
219 Assignment of function Assignment of function outputs, activated in F13 forward;
F13 Forward A see CV129 0-255 0
220 Assignment of function Assignment of function outputs, activated in F15 forward;
F13 Forward B see CV130 0-255 0
221 Assignment of function Assignment of function outputs, activated in F13 forward;
F13 Forward C Soundslot 1 - 16 0-16 0
222 Assignment of function Assignment of function outputs, activated in F13 backward;
F13 Backward A see CV132 0-255 0
223 Assignment of function Assignment of function outputs, activated in F13 backward;
F13 Backward B see CV133 0-255 0
224 Assignment of function Assignment of function outputs, activated in F13 backward;
F13 Backward C Soundslot 1- 16 0-16 0
225 Assignment of function Assignment of function outputs, activated in F14 forward;
F14 Forward A see CV129 0-255 0
226 Assignment of function Assignment of function outputs, activated in F14 forward;
F14 Forward B see CV130 0-255 0
