Esu LokProgrammer User Manual

33
CVCV
CVCV
CV
NameName
NameName
Name
DescriptionDescription
DescriptionDescription
Description
RangeRange
RangeRange
Range
DefDef
DefDef
Def
227 Assignment of function Assignment of function outputs, activated in F14 forward;
F14 Forward C Soundslot 1 - 16 0-16 0
228 Assignment of function Assignment of function outputs, activated in F14 backward;
F14 Backward A see CV132 0-255 0
229 Assignment of function Assignment of function outputs, activated in F14 backward;
F14 Backward B see CV133 0-255 0
230 Assignment of function Assignment of function outputs, activated in F14 backward;
F14 Backward C Soundslot 1- 16 0-16 0
231 Assignment of function Assignment of function outputs, activated in F15 forward;
F15 Forward A see CV129 0-255 0
232 Assignment of function Assignment of function outputs, activated in F15 forward;
F15 Forward B see CV130 0-255 0
233 Assignment of function Assignment of function outputs, activated in F15 forward;
F15 Forward C Soundslot 1 - 16 0-16 0
234 Assignment of function Assignment of function outputs, activated in F15 backward;
F15 Backward A see CV132 0-255 0
235 Assignment of function Assignment of function outputs, activated in F15 backward;
F15 Backward B see CV133 0-255 0
236 Assignment of function Assignment of function outputs, activated in F15 backward;
F15 Backward C Soundslot 1- 16 0-16 0
237 Assignment of function Assignment of function outputs, activated in Sensor 1 forward;
Sensor 1 Forward A see CV129 0-255 0
238 Assignment of function Assignment of function outputs, activated in Sensor 1 forward;
Sensor 1 Forward B see CV130 0-255 0
239 Assignment of function Assignment of function outputs, activated in Sensor 1 forward;
Sensor 1 Forward C Soundslot 1 - 16 0-16 0
240 Assignment of function Assignment of function outputs, activated in Sensor 1 backward;
Sensor 1 Backward A see CV132 0-255 0
241 Assignment of function Assignment of function outputs, activated in Sensor 1 backward;
Sensor 1 Backward B see CV133 0-255 0
242 Assignment of function Assignment of function outputs, activated in Sensor 1 backward;
Sensor 1 Backward C Soundslot 1- 16 0-16 0
243 Assignment of function Assignment of function outputs, activated in Sensor 2 forward;
Sensor 2 Forward A see CV129 0-255 0
244 Assignment of function Assignment of function outputs, activated in Sensor 2 forward;
Sensor 2 Forward B see CV130 0-255 0
245 Assignment of function Assignment of function outputs, activated in Sensor 2 forward;
Sensor 2 Forward C Soundslot 1 - 16 0-16 0
246 Assignment of function Assignment of function outputs, activated in Sensor 2 backward;
Sensor 2 Backward A see CV132 0-255 0
247 Assignment of function Assignment of function outputs, activated in Sensor 2 backward;
Sensor 2 Backward B see CV133 0-255 0
248 Assignment of function Assignment of function outputs, activated in Sensor 2 backward;
Sensor 2 Backward C Soundslot 1- 16 0-16 0
249 Minimum distance of The time interval in milliseconds that the steam chuffs can have to each other 0-255 0
the steam chuffs
250 Time for the steam Relative throughput time of one steam shifts 0-255 0
shifts flow
251 Earliest relative starting Relative distance of the steam Shifts to the previous chuff 0-255 0
position for Steam Shift
252 Latest relative starting Relative distance of the steam shifts to the subsequent chuff 0-255 0
position for Steam Shift
CV Overview Chart

Esu LokProgrammer Specifications

General

Interface	USB
Type	Decoder programmer
Compatibility	ESU decoders
Software	LokProgrammer software
Power Supply	USB
Supported Protocols	DCC, Motorola, M4
Function	Decoder programming, sound file upload
Operating System	Windows, MacOS
