Menu reference SwitchPilot 3 Plus
Menu reference SwitchPilot 3 Plus
09
OUTPUT MODE 7
Mode : Impulse
Time : 520ms
Zoom : Disabled
Mode: IMPULSE | PECO | K83 | K84 |AltFlash
Time: 130 ms | 195 ms | .. 2015 ms
Zoom: Disabled | Enabled
10
OUTPUT MODE 8
Mode : Impulse
Time : 520ms
Zoom : Disabled
Mode: IMPULSE | PECO | K83 | K84 |AltFlash
Time: 130 ms | 195 ms | .. 2015 ms
Zoom: Disabled | Enabled
11
FADEIN & FADEOUT
Time : 65 ms
Time: 0 ms | 65 ms .. 4160 ms
12
RAILCOM
Mode : Enabled
CH2 : Enabled
Mode: Enabled | Disabled
CH2 : Enabled | Disabled
13
INFORMATION
HW : 3.0
SW : 3.0.9
Voltage : 18.4V
HW: Hardware version of the decoder.
SW: Software version of the decoder. Update with LokProgrammer
Voltage: Supply voltage of the decoder (if necessary rail tension)
14
OUTPUT STATE
1 2 3 4 5 6 7 8
CMD .».»».».»..».»».
PHY .».»..».»....»».
