Esu SwitchPilot 3 Plus - List of all supported CVs

30
CV Name Description Range Value
1 Decoder address 1,
LSB
Lower 6 bits (bit 0 - 5) of the first decoder address for outputs 1 to 4. Used together with CV
9 to save the address.
1 - 63 1
3 Configuration
Output 1
Defines the properties of decoder output 1. 0 - 64 8
Function Description Value
Moment
business
K83-compatible: output active as long as the button on the control
panel is pressed.
0
Impulse ope-
ration PECO
Impulse operation for PECO drives. Reduces the sensitivity of the
overcurrent protections.
1
Impulse ope-
ration
Duty cycle: multiple of 65 ms. 2 - 31
Alternating
indicators
Out A and Out B alternately active. Duty cycle: multiple of 130 ms. 32 - 63
Continuous bis-
table operation
K84 compatible: Either Out A or Out B active, permanent output. 64
4 Configuration
Output 2
Defines the properties of decoder output 2. 0 - 64 8
Function Description Value
- As CV 3 -
5 Configuration
Output 3
Defines the properties of decoder output 3. 0 - 64 8
Function Description Value
- As CV 3 -
6 Configuration
Output 4
Defines the properties of decoder output 4. 0 - 64 8
Function Description Value
- As CV 3 -
7 Version number Internal software version of the decoder 194
8 Manufacturer ID Manufacturer number (ID) of ESU. Writing the value 8 resets all CV to the factory
setting.
- 151
9 Decoder address 1,
MSB
Upper 3 bits (bits 6 - 8) of the first decoder address for outputs 1 to 4.
Used together with CV 1 to save the address.
0 - 7 0
List of all supported CVs
