32
CV Name Description Range Value
37 DCC turnout
addressing
Calculation of the turnout numbers from the decoder address 0,1 0
Bit Description Value
0 DCC turnout addressing compliant with RCN-213
DCC turnout addressing for ROCO centers
0
1
38 Configuration
output 5
Defines the properties of decoder output 5. 0 - 64 8
Function Description Value
- As CV 3 -
39 Configuration
output 6
Defines the properties of decoder output 6. 0 - 64 8
Function Description Value
- As CV 3 -
40 Configuration
output 7
Defines the properties of decoder output 7. 0 - 64 8
Function Description Value
- As CV 3 -
41 Configuration
output 8
Defines the properties of decoder output 8. 0 - 64 8
Function Description Value
- As CV 3 -
42 Fadein / Fadeout
Time
Duration of the fade-in & fade-out process in 65ms steps, if configured for the output. 0 - 63 2
