INSTALLATION NOTES
1
5 14
16
15
Double DIN Radio
Decoration Panel
Bend the appropriate tabs to hold the
mounting frame firmly in place.
Main Device
Connect all required connections (5-14) with the Main Device
Double DIN Mounting Frame
Dashboard
Dashboard installation
VNA-630-F
In some cases a smaller and more shallower
mounting frame is required.
Outer dimensions: 102 mm heigth, 189 mm width
Recommended accessories:
