GB
MD 360/8 Basic MD 360i/24 Basic MD 360/24 Basic SMB
MD 360i/8 Basic MD 360/8 Basic SMB MD 360i/24 Basic SMB
MD 360/24 Basic MD 360i/8 Basic SMB
Function Customised setting
PDi/MDi
Remote control
Functions
Channel 1
Channel 2
System
Bat ok LS MDi
To configure temporary settings, select the sub-item “Functions” in the “PDi/MDi”
menu.
Functions
ON/OFF
Test
Reset
4 h ON/OFF
Bat ok LS MDi
ON / OFF
Switching the lighting ON / OFF manually.
Note: The “4h ON / OFF” mode cannot be interrupted using the “ON / OFF” function; it
can only be interrupted using the “Reset” function.
“ON” acknowledgement: Movement detected in the field of detection is acknowledged
with one short flash of the red LED.
“OFF” acknowledgement: Movement detected in the field of detection is not
acknowledged.
Functions
ON/OFF
Test
Reset
4 h ON/OFF
Bat ok LS MDi
Reset / settings
Temporarily set values are cleared. The detector returns to the preset operating mode.
Functions
ON/OFF
Test
Reset
4 h ON/OFF
Bat ok LS MDi
4h ON / OFF
The lighting is switched on or off continuously for approx. 4 hours. If no movement is
detected in the field of detection and the preset switch-off delay time has elapsed, the
detector returns to the previous operating mode.
Note: The “4h ON / OFF” mode can be temporarily exited using the “Reset” function.
Acknowledgement: slow flashing.
