GB
MD 360/8 Basic MD 360i/24 Basic MD 360/24 Basic SMB
MD 360i/8 Basic MD 360/8 Basic SMB MD 360i/24 Basic SMB
MD 360/24 Basic MD 360i/8 Basic SMB
3 Operation / functionality
• 360° field of detection, 8 m / 24 m range at an installation height of 2.5 m
• Automatically controlled lighting channels when motion is detected
• With zero-cross switching
3.1 Conditions in which the lighting is switched on
The lighting is switched on if the target brightness value is below the preset lux
value and movement is detected in the field of detection. Further movement is
acknowledged by the sensor with two short flashes of the red LED (the LED can be
switched off; see “Configuring parameters via remote control”).
Once the lighting has been switched on, the sensor deactivates light measurement for
this period.
3.2 Conditions in which the lighting is switched off
The lighting is switched off if no movement is detected in the field of detection and
the preset switch-off delay time has elapsed
3.3 Switching delay – not in pulse mode
When persons are present, in order to avoid sudden changes in brightness caused by
undesired switching on / off of the lighting, the detector will only be triggered after a
time delay.
Example: a passing cloud could potentially cause unnecessary switching.
Time delay from light to dark: 30 sec. = red LED lights up during this period.
Time delay from dark to light: none = only switch-off delay active.
