GB
MD 360/8 Basic MD 360i/24 Basic MD 360/24 Basic SMB
MD 360i/8 Basic MD 360/8 Basic SMB MD 360i/24 Basic SMB
MD 360/24 Basic MD 360i/8 Basic SMB
6.4 Mobil-PDi/MDi temporary settings
Parameter configurations are only temporarily applied.
Function Customised setting
ON / OFF
Switching the lighting ON / OFF manually.
Note: The “ON / OFF” mode can be cancelled by pressing the “Reset” button.
“ON” acknowledgement: Movement detected in the field of detection is
acknowledged with two short flashes of the red LED.
“OFF” acknowledgement: Movement detected in the field of detection is
acknowledged with one short flash of the red LED.
Reset / settings
Temporarily set values are cleared and the detector returns to the manually
preset operating mode.
4h ON / OFF
The lighting is switched on or off continuously for approx. 4 hours. If no
movement is detected in the field of detection and the preset switch-off delay
time has elapsed, the detector returns to the previous operating mode.
Note: The “4h ON / OFF” mode can be cancelled by pressing the “Reset” button.
6.5 Programming the Mobil-PDi/MDi
Alterations to parameters are applied permanently.
Function Customised setting
Enter programming mode
The detector goes into programming mode.
Acknowledgement: The red LED lights up permanently and the lighting is
switched on continuously.
Exit programming mode
The set parameters are stored on the detector.
Acknowledgement: The red LED is switched off.
