MD 360/8 Basic MD 360i/24 Basic MD 360/24 Basic SMB
MD 360i/8 Basic MD 360/8 Basic SMB MD 360i/24 Basic SMB
MD 360/24 Basic MD 360i/8 Basic SMB
Function Customised setting
Channel 1
Read-in
Light
Time
Reset
LEDs ON/OFF
Fully/semi-automatic
Bat ok LS MDi
Time
5 min
Bat ok LS MDi
Switch-off delay time
Setting values: Short pulse, 1, 2, 5, 10, 15 min.
Short pulse
As soon as movement has been detected in the field of detection, the detector switches
the lighting on for approx. 5 second and off for approx. 5 seconds. This function can be
used for operating automatic stairwell lights, for example.
Acknowledgement: The red LED is switched on for 5 seconds and off for 5 seconds.
Switch-off delay time: 1, 2, 5, 10, 15 min.
The switch-off delay time starts once movement is no longer detected in the field of
detection.
Acknowledgement: The red LED flashes three times in cycles.
Channel 1
Read-in
Light
Time
Reset
LEDs ON/OFF
Fully/semi-automatic
Bat ok LS MDi
Reset / factory settings
The remote control settings are reset and the detector uses the manual potentiometer
values.
Acknowledgement: The red LED flashes three times.
Channel 1
Read-in
Light
Time
Reset
LEDs ON/OFF
Fully/semi-automatic
Bat ok LS MDi
Detector LEDs ON / OFF
The LEDs in the detector can be switched on or off by pressing the button.
Acknowledgement:
LEDs OFF: The red LED is switched off for approx. 2 seconds.
LEDs ON: The red LED flashes three times.
Channel 1
Read-in
Light
Time
Reset
LEDs ON/OFF
Fully/semi-automatic
Bat ok LS MDi
Fully automatic / semi-automatic mode
The lighting can be controlled in fully automatic and semi-automatic modes by
pressing the button.
Fully automatic: The lighting is switched on depending on the set lux value and
movement being detected. If movement is no longer detected, the preset switch-off
delay time will start. This mode can be optionally switched on or off using the external
“S” button.
Acknowledgement: The red LED flashes three times.
Semi-automatic: The lighting is controlled using the external “S” button. The lighting
remains switched on as long as movement is detected and the target brightness value
is greater than the preset lux value.
Acknowledgement: The red LED is switched off for approx. 2 seconds.
