eta Aron - CHARGER STATION; REMOTE CONTROL; MOP EXTENSION

EN - 50
EN
3.5 CHARGER STATION
D
D1
E
D2
D3
D – Charger station
D1 – Operation indicator
D2 – Power adapter connector
D3 – Charging contacts
E – Power adapter
3.6 REMOTE CONTROL
F
F1
F2
F3
F5
F4
F6
F7
F8
F9
F – Remote control
F1 – Display
F2 – Smart (automatic cleaning) /
STOP (PAUSE) / button
F3 – Directional buttons for manual
control
F4 – Button for setting the scheduled
cleaning time
F5 – MAX button for setting the
suction power level
F6 – Classic cleaning button
F7 – Button for setting the current time
F8 – Local cleaning button
F9 – Button for return to charging
station
3.7 MOP EXTENSION
G
G1
G2
G3
G – Mop extension
G1 – Rubber stopper
G2 – The lower part for attaching the mop
G3 – Mop
