eta Pellets Compact - Clean the Inner Walls of the Combustion Chamber; Clean the Ignition Tube; Check the Movability of the Firebed Switch

18 www.eta.co.at
Cleaning (customer) Cleaning and maintenance
Cleaning the inner walls of the combustion
chamber
Strip off the ashes on the inner walls of the combustion
chamber and stoke them on the grate.
Fig. 2-23: Cleaning the inner walls
Cleaning the ignition tube
Clean the ignition tube by suction and carefully remove
any deposits.
Fig. 2-24: Ignition tube
Checking the movability of the firebed switch
Check the movement of the firebed lever in the
combustion chamber by repeated lifting.
Fig. 2-25: Firebed lever
Replacing the combustion chamber cover
Clean the combustion chamber cover and replace it
into the combustion chamber.
Fig. 2-26: Combustion chamber cover
