Cleaning and maintenance Maintenance (expert)
Removing the cover from the front
Remove the cover from the front of the boiler.
Fig. 2-31: Cover
2.6.3 Clean draught fan
Clean the draught fan and fan housing
Unplug the draught fan's power supply. Loosen the
nuts and remove the draught fan.
Fig. 2-32: Draught fan
Remove the ash from the fan housing.
Fig. 2-33: Fan housing
